Detailed information about the image sensor for the camera of the iPhone 14 Pro Max was posted on the Chinese social media Weibo.
Image sensor for iPhone14 Pro Max
According to the information posted on Weibo, all image sensors for the iPhone14 Pro Max cameras are manufactured and supplied by Sony, and the model numbers of the image sensors for each camera are as follows.
| Camera type | image sensor model number |
|---|---|
| rear wide angle camera | IMX803 |
| Rear ultra-wide-angle camera | IMX633 |
| rear telephoto camera | IMX713 |
| Rear LiDAR scanner | IMX590 |
| front camera | IMX714 |
Of the camera image sensors of the iPhone14 Pro Max, only the rear telephoto camera and rear LiDAR scanner are common to the iPhone13 Pro Max, and the others have been changed to new ones, the poster said.
Specifications of the new image sensor
The image sensor of the rear wide-angle camera of the iPhone13 Pro Max was Sony’s IMX703, with a pixel pitch of 1.9 micrometers (μm).
The pixel pitch of the image sensor of the rear wide-angle camera of the iPhone14 Pro Max is 1.22 μm, and it functions as 2.44 μm when outputting with 12 million pixels.
The image sensor of the rear ultra-wide-angle camera of iPhone13 Pro Max is Sony’s IMX772, and the pixel pitch was 1 μm, but it seems that the iPhone14 Pro Max has been enlarged to 1.4 μm.
The image sensor for the front camera was also changed from IMX514 in iPhone13 Pro Max to IMX714 in iPhone14 Pro Max.
Source: Weibo via Notebookcheck
Photo: Apple Hub/Facebook
(FT729)
