It’s been a while ! Inspired by Apple’s Mac Studio, I challenged myself to design and build the smallest PC I could without compromising on practicality.
As ultra-compact computers continue to grow in popularity, I wanted to see if it was possible to create a clean, minimalist system capable of delivering a solid gaming experience, all without a dedicated graphics card. This video takes you through the entire journey, from the custom design and 3D printing process to the final assembly and performance testing.
I hope you enjoy the build as much as I enjoyed creating it!
SCPC
STL Link : https://makerworld.com/en/models/3086914-itx-pc-case-mac-sutdio-style#profileId-3477496
Ryzen 7 8700G Undervolting Settings ( Bios )
* Precision Boost Overdrive (PBO): Advanced
* Curve Optimizer: All Cores
* Curve Optimizer Sign: Negative
* Curve Optimizer Magnitude: 20
* PPT Limit: 65 W
* TDC Limit: 90 A
* EDC Limit: 120 A
Integrated Graphics (iGPU):
* GFX Clock Frequency: 2500 MHz
* GFX Voltage: Auto (0 )
Gamins PC :
CPU : AMD Ryzen 7 8700G https://amzn.to/3RKlJzX
MOBO : ASRock AMD B850i https://amzn.to/4wa1w5w
RAM : CORSAIR Vengeance DDR5 RAM 32GB https://amzn.to/3ThVuRM
SSD : WD_Black SN7100 1TB NVMe https://amzn.to/4wbGLX3
CPU COOLER : Thermalright AXP90-X47 https://amzn.to/4yvQo4w
CPU COOLER FAN : ARCTIC P12 Slim Fan https://amzn.to/4wQwPlJ
CHASSIS FANS : Noctua NF-A4x20 Fan https://amzn.to/3Rmw6tG
Hardware :
240W Slim Laptop Charger https://amzn.to/45ibGFk
RGEEK Pico PSU
https://www.aliexpress.com/item/1005002603961845.html
ELEGOO Gray Glass Fiber PETG Filament https://amzn.to/45lnhmY
DC 7.4mm x 5.0mm to 5.5mm x 2.5mm Power Adapter https://amzn.to/3RONGGL
12mm Power Button https://amzn.to/4gMkcn9
M3x4x5mm Heat Insert https://amzn.to/4mOAKMo
Screws Assortment Kit https://amzn.to/4t1M0XR
